To safely spray dry inflammable solvents,a new operating principle is employed which uses a combination of the Spray Dryer YC-015 and the Inert Loop to provide a closed loop circulation under inert conditions. The absence of oxygen prevents the formation of a ignitable mixture.At the same time, the solvent contained in the gas stream is cooled and consequently condensed. The regenerated flow is then returned again to the spray dryer.
The Mini Inert loop spray dryer YC-015A is the result of 15 years continuous development ,is your choice for the quick and gentle drying to powder of aqueous and organic solutions. The impressive features of the Spray Dryer include its efficient performance with very short set-up times,an effective integrated nozzle cleaning mechanism and a high degree of flexibility thanks to the different cylinder geometries.
Power | 5000W | Voltage | 220V,50-60Hz |
Min.Outlet Temperature | 40℃ | Capacity | 1500ml/h |
Airflow | 0-330㎡/h | Max.Inlet Temperature | 200℃ |
Heater Power | 3500W | Temperature Precision | ±1℃ |
