Description
The spray drying is the widest used technology in the liquid shaping technology and in the drying industry. It is most suitable for producing powder, particle, or block solid products from materials of solution, emulsion, soliquoid and pumpable paste states. Therefore, when the particle size and distribution of the final products, their residual water contents, the stocking density and the particle shape meet the precision standards, the spray drying is one of the most desired technologies.
Feature
1, High speed of drying. After the spraying of he material liquid, the surface area of the material will be increased greatly. In the hot-air flow, 95%-98% of water can be evaporated at a moment. The time of completing the drying needs only several seconds.
2, It is especially suitable for drying the heat sensitive materials. It’s final products own the good uniformity, mobility, dissolving capacity. And the final products are high in purity and good in quality.
3, The production procedure is simple and the operational control is easy. The liquid with the moisture contents 40-60%(for special materials, the contents may reach 90%) can be dried into power or particle products once a time. After the drying, there is no need for smashing of sorting, so as to reduce the operation procedures in the production and enchance the purity. The product particle diamenters, looseness and water contents can be adjusted through changing the operation condition in a certain scope. It is very convenient to carry out the control and management.
Technical parameters
|
type |
5 |
25 |
50 |
100 |
150 |
200 |
500 |
800 |
1000 |
2000 |
3000 |
4500 |
6500 |
|
Inlet air temperature(℃) |
140-350 |
||||||||||||
|
Outlet air temperature(℃) |
80-90 |
||||||||||||
|
Atomizing way |
High speed centrifugal atomizer(mechanical transmission) |
||||||||||||
|
Evaporation(kg/h) |
5 |
25 |
50 |
100 |
150 |
200 |
500 |
800 |
1000 |
2000 |
3000 |
4500 |
6500 |
|
Diameter of atomizing disc(mm) |
60 |
120 |
150 |
180-210 |
According to the requirement of technical process |
||||||||
|
Electrical heating power(k w) |
8 |
31.5 |
60 |
81 |
99 |
Use other heat source |
|||||||
|
Powder product recovery rate |
About 95% |
||||||||||||
|
Occupied length(m) |
1.6 |
4 |
4.5 |
5.2 |
7 |
7.5 |
12.5 |
13.5 |
14.5 |
Decided by the requirement of technical process, site condition |
|||
|
Occupied width(m) |
1.1 |
2.7 |
2.8 |
3.5 |
5.5 |
6 |
8 |
12 |
14 |
||||
|
Height of tower(m) |
1.75 |
4.5 |
5.5 |
6.7 |
7.2 |
8 |
10 |
11 |
15 |
||||
FAQ
Q: Why we believe in YINUO DRYING ?
A:
1. More than 20 years experience.
2. YINUO a is the leading professional supplier of solution, equipments and service for drying, mixing, crushing, screening and airflow conveying industry.
3. All products achieved ISO9001:2000 quality management certificate and EU CE certificate.
Q: Delivery time
A: The lead time is 10-70 days, Delivery time will vary depending on the type of the machine, shipping method selected and part availability.
Q: Payment terms
A: Accepted Payment Type: T/T, L/C, Western Union, Cash
After sign the contract, pay the 10%-30% deposit of total purchase price and pay the full payment before delivery but after inspection.
Q: Packing of goods
A: 1.Sand blasting, coat with high quality paint;
2.Product wrap by PP-Bubble
3.Load container, Spear Parts in wooden case.
Q: How is quality warranty?
A:Guarantees the machines are new (or unused) and the guarantee period will be 12(twelve) months. During this period, the seller will provide free maintenance and free spare parts that caused by the machine’s quality.
Q: What will you do if the machine is broken down after guarantee period?
A: We will provide the technical advice and find the solution immediately for you when the machine is in trouble. For those wear parts, we guarantee the high quality parts for long-term supply.
Q: What should I do if I want to get a best quotation?
A: If you want a suitable type of machine for you, we would like to get the following information:
What is the raw material name?
Material related characteristic? Does it corrosive, strong basicity, or highly acid?
What is the capacity per hour you need (kg/h)?
What is the initial moisture and final moisture of finished products you require to get?
What about the maximum heat temperature of raw material?
What kind of heating way you use to heat the dryer? Natural gas, electricity, fuel oil or steam?
Which equipment material do you like prefer? SUS304, SUS316L or Carbon steel?
Provide us your country’s power supply,such as phases, voltage, HZ?
Q: Is installation service free?
A: Yes, each machine from our company, we supply free installation.
We will help you to design, install and deliver your plant to get the best possible performance out of your equipment and plant right from the start.
Q: Is training service free?
We will train your staff and offer you standard training packages on your site for free.
training includes:
Safety training
Operator training
Technical/maintenance training
Machine process training
