Large evaporation Vegetable&fruit juice extract powder centrifugal Industrial spray dryer equipment machine price

1 Set
MOQ
$84,000.00(1 - 1 Sets) $82,000.00(>=2 Sets)
Price
Large evaporation Vegetable&fruit juice extract powder centrifugal Industrial spray dryer equipment machine price
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Spray Drying Equipment
Application: Medicine Processing, Chemicals Processing, Food Processing
Condition: New
Dimension(L*W*H): 7.5m*6m*8m
Key Selling Points: Automatic
Warranty: 1 Year
Weight (KG): 15000
Applicable Industries: Manufacturing Plant, Food & Beverage Factory, Farms
Showroom Location: None
Marketing Type: Other
Machinery Test Report: Provided
Video Outgoing-inspection: Provided
Warranty Of Core Components: 1 Year
Core Components: Bearing, Pump, Gear, Motor, Gearbox, PLC, Engine
Evaporation Capacity(kg/h): 200
Heating Method: Steam Heating
Material: SUS304, SUS304L, SUS316, SUS316L, Other
Heating Source: Electricity,steam+electricity,oil Fuel,gas Fuel,hot Air Furnace
System Material: All SUS304/316L
After-sales Service Provided: Online Support, Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training
After Warranty Service: Video Technical Support, Online Support, Spare Parts
Local Service Location: None
Certification: CE,ISO9001,ISO14001
Basic Infomation
Certification: CE,ISO9001,ISO14001
Payment & Shipping Terms
Packaging Details: as per customer's requirement
Supply Ability: 20 Set/Sets per Year
Product Description
Product Overview

LPG-200 Vegetable&fruit juice extract powder centrifugal spray dryer machine

The spray drying is the widest used technology in the liquid shaping technology and in the drying industry. It is most suitable for producing powder, particle, or block solid products from materials of solution, emulsion, soliquoid and pumpable paste states. Therefore, when the particle size and distribution of the final products, their residual water contents, the stocking density and the particle shape meet the precision standards, the spray drying is one of the most desired technologies.
FEATURES AT A GLANCE
1,  High speed of drying. After the spraying of he material liquid, the surface area of the material will be increased greatly. In the hot-air flow, 95%-98% of water can be evaporated at a moment. The time of completing the drying needs only several seconds. 2,  It is especially suitable for drying the heat sensitive materials. It’s final products own the good uniformity, mobility, dissolving capacity. And the final products are high in purity and good in quality.
3.Typical application:
Food: Amino acid, vitamin, egg powder, bone powder, flavouring, protein, milk powder, blood powder, soy sauce powder, coffee, tea powder, glucose, pentadiene carboxylic acid, pectin, flavours, vegetable juice, yeast, starch, etc.
Ceramic Alumina, zirconia, magnesium oxide, titania, pottery clay, china clay, all kinds of magnetic porcelain and metal-oxides,
etc

Chemical: Aluminium polychlorid, disperse dyes, reactive dyes, organic catalyzer, white carbon black, washing powder, zinc sulfate,
silica, sodium metasilicate, potassium fluoride, calcium carbonate, potassium sulfate, ingotganic catalyzer and all kinds of waste
liquid, etc


PRODUCT SPECIFICATIONS
No
Item
Data
1
moisture evaporation amount
200kg/h
2
operation temputure
input air160~220℃,output air 80-100℃
3
Tower outer diameter / tower net height
3.2m/8m
4
Atomizer speed
16000r.p.m
5
Atomization type
Centrifugal atomization
6
Heating source
steam+electricity
7
Product collection method
First-class cyclone + water film dust removal
Other model technical parameters


Component system
Sketch of Flow Chart
